Classic Princess Cut Halo Ring CAD Model - Professional Rings CAD Design

SKU: JDH-RNG-002

Design Gallery Views

Classic Princess Cut Halo Ring CAD Model perspective render view 1

Classic Princess Cut Halo Ring CAD Model perspective render view 2

Classic Princess Cut Halo Ring CAD Model perspective render view 3

Watertight STL Verified

Instant 980GB Access

Pre-Cut Gem Seats

Commercial Rights

Halo Rings CAD Collection

Classic Princess Cut Halo Ring CAD Model

Princess cut center diamond surrounded by a micro-pave halo and split shank band CAD model.

Technical Specifications

File Size:18.5 MB

Polygon Density:32,400 Quads

Engineering Tolerances:0.01 mm precision

Gemstone Details:1.2 Ct Princess Center + 16 x 1.3mm Melee Diamonds (0.16 ctw)

Pre-Calculated Metal Weights

14K Gold

4.8g

18K Gold

5.9g

Platinum

7.6g

Silver

3.8g

Compatible Software:

Rhino 3D MatrixGold Blender JewelCAD

Included Formats:

3DM STL PNG MP4

Get Access to This Design & 5,000+ More — €79

Instant Google Drive download link delivered after payment.

Design Overview & Manufacturing Notes

High-fidelity Classic Princess Cut Halo Ring 3DM CAD file. Designed for a 1.2 Ct princess cut stone (6.0mm x 6.0mm) surrounded by sixteen 1.3mm round accent diamonds on the halo. The split shank architecture includes pre-cut seat recesses and bead prongs. Supplied with editable Rhino 3DM NURBS curves and production-ready castable STL files for gold or platinum casting.

Frequently Asked Questions

What file formats are included with this design?

Every design download includes editable Rhino 3D (.3DM) source files, watertight 3D printable (.STL) meshes, 4K transparent (.PNG) render sheets, and 360-degree (.MP4) turntable videos.

Can this design be customized?

Yes. Because the 3DM file retains clean NURBS surfaces and un-trimmed geometry, you can easily alter ring finger sizes, gem seat depths, or prong heights in Rhino 3D, MatrixGold, or JewelCAD.

Which software can open these files?

These files can be opened and edited in Rhino 3D, MatrixGold, Blender, JewelCAD. The exported STL files are universally compatible with all SLA/DLP 3D printer slicer software.
